Rockstar 400 Plates

Rockstar 400 Suppliers, Rockstar 400 Steel Plates, Rockstar 400 Abrasion Resistant Steel Plates Stockists, Wholesaler, Mumbai, India

Rockstar 400 Wear Resistant Steel Plates, Rockstar 400 Wear Plates, 400 Rockstar Hot Rolled Plate, Cold Rolled Rockstar 400 Steel Plate Dealer, Supplier

Aspirinox Alloys Inc is one of the leading manufacturer supplier and exporter of ROCKSTAR 400 Plates. Rockstar 400 is a wear resistant rapidly cooled and tempered steel plate grade having an excellent combination of hardness, formability, weldability and toughness to meet all types of fabrication requirements. It was designed with relatively low carbon equivalent for better weldable properties.



Rockstar 400 Abrasion Resistant Plates are mainly used for fabrication of crushers, liners for truck beds, buckets, hoppers, chutes, excavators and conveyor troughs, concrete mixer drums, trash truck bottoms, bucket lips, street sweepers and dump trailers and many other purposes.



Rockstar 400 plates have obtained its mechanical properties by quenching which means cooling rapidly and when required by subsequent tempering. The new condition cannot be retained after service which exceeds a temperature of 250 degree Celsius. Rockstar 400 is not intended for further heat treatment.



Rockstar 400 Wear Resistant Plates has a chemical composition of carbon manganese molybdenum sulfur chromium nickel silicon boron and phosphorus their composition percentage depends on the dimensions of the Plates used for various applications. The Rockstar 400 plates are delivered with thermally cut edges. Untrimmed edges can also be delivered after an agreement. Call us now and request a free quote!

Rockstar 400 Plates Specifications

Specifications for Rockstar 400 Plates. If any specification is not mentioned here, please use the contact button for quick quote.

Item Abrasion Resistant Plate
Material Rockstar 400
Thickness 6mm to 75mm
Width 1,500mm to 2,500mm
Length 6,000mm to 12,000mm
Heat Treatment N, Q+T
Surface Paint EP, PE, HDP, SMP, PVDF
Width 1,500mm to 2,500mm
Thickness Tolerances Thickness tolerance as per EN 10029. Narrower tolerances can also be offered.
Length and Width  Tolerances as per the requirements of EN 10029
Flatness Tolerances as per the requirements of EN 10029 Class N
Surface Properties Tolerances as per the requirements of EN 10163-2, Class A Subclass 1

Rockstar 400 Plates Chemical Composition

Plate Thickness mm 6.0 – 20.0 21.0 – 32.0 32.1 – 50.0 50.1 – 75.0
C Max % 0.16 0.18 0.22 0.22
Mn Max % 1.60 1.60 1.60 1.60
P Max % 0.025 0.025 0.025 0.025
S Max % 0.010 0.010 0.010 0.010
Si Max % 0.70 0.70 0.70 0.70
Cr Max % 0.50 1.00 1.40 1.40
Ni Max % 0.25 0.25 0.50 0.50
Mo Max % 0.25 0.25 0.60 0.60
B Max % 0.0040 0.0040 0.0040 0.0040
CE Max % 0.45 0.48 0.57 0.65
PCM Max % 0.28 0.29 0.33 0.40

Rockstar 400 Plates Mechanical Properties

360-430 BHN (On a milled surface 0.5-2 mm below the plate surface)
Hardness Typical values for 20 mm
Yield Strength (MPa) 1000
Tensile Strength (MPa) 1250
% Elongation (L0=50 mm) 12
Impact at -30°C (In Joules) 40

Rockstar 400 Plates Material Application

  • Conveyors
  • Dump Truck Bodies
  • Loading Buckets & Bulldozers

  • Chutes
  • Crushers

Rockstar 400 Plates Price List

Request the latest Rockstar 400 Plates List. Please click on the request a quote button or click here to request the updated price list and ready stock information along with your requirement. Aspirinox Alloys INC maintains a stock of all standard items and can export them at best price for Rockstar 400 Plates.

Rockstar 400 Plates - Value Added Services

Material Testing:

  • Mechanical Testing Such as Tensile of Area
  • Hardness Test
  • Chemical Analysis – Spectro Analysis
  • Positive Material Identification – PMI Testing
  • Flattening Test
  • Micro and MacroTest
  • Pitting Resistance Test
  • Flaring Test
  • Intergranular Corrosion (IGC) Test

Documentation & Packaging:

  • Commercial Invoice including HS Code
  • Packing List including Complete Details
  • Certificate of Origin legalized
  • Material Traceability Records
  • Quality Assurance Plan (QAP)
  • Heat Treatment Charts
  • Material Test Certificates (MTC)
  • Guarantee Letter
  • NABL approved Laboratory Test Reports

Exporting Rockstar 400 Plates to Below Countries

Afghanistan, Albania, Andorra, Austria, Bahrain, Bangladesh, Bhutan, Brunei, Belarus, Belgium, Bulgaria, Cambodia, China, Cyprus, Croatia, Czech Republic, Denmark, Estonia, Egypt, Finland, France, Germany, Greece, Georgia, Hungary, Iceland, Ireland, Italy, Indonesia, Iran, Iraq, Israel, Japan, Jordan, Kazakhstan, Kuwait, Kyrgyzstan, Lebanon, Latvia, Latin America, Liechtenstein, Lithuania, Luxembourg, Malta, Moldova, Monaco, Malaysia, Maldives, Mongolia, Myanmar (Burma), Nepal, North Korea, Netherlands, Norway, Oman, Poland, Portugal, Pakistan, Palestine, Philippines, Qatar, Russia, Romania, Russia, San Marino, Serbia and Montenegro, Slovakia, Slovenia, Spain, Sweden, Switzerland, Saudi Arabia, Singapore, South Korea, South Africa, Sri Lanka, Syria, Taiwan, Tanzania, Tajikistan, Thailand, Turkey, Turkmenistan, Ukraine, United Kingdom, United Arab Emirates (UAE), Uzbekistan, Vietnam, Yemen

Supplying Rockstar 400 Plates to Following Domestic Cities

Mumbai, Delhi, Kolkata, Chennai, Bengaluru, Hyderabad, Ahmadabad, Pune, Surat, Jaipur, Kanpur, Lucknow, Nagpur, Ghaziabad, Indore, Coimbatore, Kochi, Patna, Kozhikode, Bhopal, Thrissur, Vadodara, Agra, Malappuram, Thiruvananthapuram, Kannur, Ludhiana, Nashik, Vijayawada, Madurai, Varanasi, Meerut, Faridabad, Rajkot, Jamshedpur, Srinagar, Jabalpur, Asansol, Vasai Virar City, Allahabad, Dhanbad, Aurangabad, Amritsar, Jodhpur, Ranchi, Raipur, Kollam, Gwalior, Durg-Bhilainagar, Chandigarh, Tiruchirappalli, Kota

Industries & Applications Where Our Rockstar 400 Plates Are Used

Chemicals, Petrochemicals, Oil & Natural Gas Organization, Fats, Fertilizers, Sugar Mills & Distilleries, Cement Industries, Ship Builders, Paper Industries, Pumps, Automation, Paints, Steel Industries, etc.
