Rockstar 450 Plates

Home Rockstar 450 Plates

Rockstar 450 Plates

Rockstar 450 Steel Plates, Rockstar 450 Suppliers, Rockstar 450 Abrasion Resistant Steel Plates Stockists, Exporter, Mumbai, India

Rockstar 450 Wear Resistant Steel Plates, Rockstar 450 Wear Plates, 450 Rockstar Hot Rolled Plate, Cold Rolled Rockstar 450 Steel Plate Dealer, Supplier

Aspirinox Alloys Inc is one of the leading stockist, supplier and exporter of ROCKSTAR 450 Plates. Rockstar 450 is a wear resistant rapidly cooled and tempered steel plate grade having an excellent combination of hardness, formability, weldability and toughness to meet different types of fabrication requirements.



Rockstar 450 Abrasion Resistant Plates has obtained its mechanical properties by quenching which refers cooling rapidly and when required by subsequent tempering. The condition of the plates can’t be retained after a service of 225 degree Celsius. Rockstar 450 is not intended for further heat treatment.



Rockstar 450 is used for fabrication of crushers, liners for truck beds, buckets, hoppers, chutes, excavators and conveyor troughs, concrete mixer drums, trash truck bottoms, bucket lips, street sweepers and dump trailers and many more. The plates are delivered with sheared or thermally cut edges. Untrimmed edges can also be delivered after an agreement.



These Rockstar 450 Wear Resistant Plates are made up of an alloy of carbon manganese molybdenum sulphuric chromium nickel silicon and boron with various chemical compositions depending upon the dimensions of the Plates used in various applications. Contact us today to get detailed information about our Rockstar 450 Plates products.

Rockstar 450 Plates Specifications

Specifications for Rockstar 450 Plates. If any specification is not mentioned here, please use the contact button for quick quote.

Item Abrasion Resistant Plate
Material Rockstar 450
Thickness 6mm to 75mm
Width 1,500mm to 2,500mm
Length 6,000mm to 12,000mm
Heat Treatment N, Q+T
Surface Paint EP, PE, HDP, SMP, PVDF
Width 1,500mm to 2,500mm

Rockstar 450 Plates Chemical Composition

Plate Thickness mm 6.0 – 20.0 21.0 – 32.0 32.1 – 50.0 50.1 – 75.0
C Max % 0.16 0.18 0.22 0.22
Mn Max % 1.60 1.60 1.60 1.60
P Max % 0.025 0.025 0.025 0.025
S Max % 0.010 0.010 0.010 0.010
Si Max % 0.70 0.70 0.70 0.70
Cr Max % 0.50 1.00 1.40 1.40
Ni Max % 0.25 0.25 0.50 0.50
Mo Max % 0.25 0.25 0.60 0.60
B Max % 0.0040 0.0040 0.0040 0.0040
CE Max % 0.45 0.48 0.57 0.65
PCM Max % 0.28 0.29 0.33 0.40

Rockstar 450 Plates Mechanical Properties

360-430 BHN (On a milled surface 0.5-2 mm below the plate surface)
Hardness Typical values for 20 mm
Yield Strength (MPa) 1000
Tensile Strength (MPa) 1250
% Elongation (L0=50 mm) 12
Impact at -30°C (In Joules) 40

Rockstar 450 Plates Material Application

  • Conveyors
  • Dump Truck Bodies
  • Loading Buckets & Bulldozers

  • Chutes
  • Crushers

Rockstar 450 Plates Price List

Contact us or click on request a quote button to get our competitive prices for Rockstar 450 Plates. Aspirinox Alloys INC maintain the large inventory of high-quality Rockstar 450 Plates for sale to our clients throughout globally.

Rockstar 450 Plates - Value Added Services

Material Testing:

  • Mechanical Testing Such as Tensile of Area
  • Hardness Test
  • Chemical Analysis – Spectro Analysis
  • Positive Material Identification – PMI Testing
  • Flattening Test
  • Micro and MacroTest
  • Pitting Resistance Test
  • Flaring Test
  • Intergranular Corrosion (IGC) Test

Documentation & Packaging:

  • Commercial Invoice including HS Code
  • Packing List including Complete Details
  • Certificate of Origin legalized
  • Material Traceability Records
  • Quality Assurance Plan (QAP)
  • Heat Treatment Charts
  • Material Test Certificates (MTC)
  • Guarantee Letter
  • NABL approved Laboratory Test Reports

Exporting Rockstar 450 Plates to Below Countries

Afghanistan, Albania, Andorra, Austria, Bahrain, Bangladesh, Bhutan, Brunei, Belarus, Belgium, Bulgaria, Cambodia, China, Cyprus, Croatia, Czech Republic, Denmark, Estonia, Egypt, Finland, France, Germany, Greece, Georgia, Hungary, Iceland, Ireland, Italy, Indonesia, Iran, Iraq, Israel, Japan, Jordan, Kazakhstan, Kuwait, Kyrgyzstan, Lebanon, Latvia, Latin America, Liechtenstein, Lithuania, Luxembourg, Malta, Moldova, Monaco, Malaysia, Maldives, Mongolia, Myanmar (Burma), Nepal, North Korea, Netherlands, Norway, Oman, Poland, Portugal, Pakistan, Palestine, Philippines, Qatar, Russia, Romania, Russia, San Marino, Serbia and Montenegro, Slovakia, Slovenia, Spain, Sweden, Switzerland, Saudi Arabia, Singapore, South Korea, South Africa, Sri Lanka, Syria, Taiwan, Tanzania, Tajikistan, Thailand, Turkey, Turkmenistan, Ukraine, United Kingdom, United Arab Emirates (UAE), Uzbekistan, Vietnam, Yemen

Supplying Rockstar 450 Plates to Following Domestic Cities

Mumbai, Delhi, Kolkata, Chennai, Bengaluru, Hyderabad, Ahmadabad, Pune, Surat, Jaipur, Kanpur, Lucknow, Nagpur, Ghaziabad, Indore, Coimbatore, Kochi, Patna, Kozhikode, Bhopal, Thrissur, Vadodara, Agra, Malappuram, Thiruvananthapuram, Kannur, Ludhiana, Nashik, Vijayawada, Madurai, Varanasi, Meerut, Faridabad, Rajkot, Jamshedpur, Srinagar, Jabalpur, Asansol, Vasai Virar City, Allahabad, Dhanbad, Aurangabad, Amritsar, Jodhpur, Ranchi, Raipur, Kollam, Gwalior, Durg-Bhilainagar, Chandigarh, Tiruchirappalli, Kota

Industries & Applications Where Our Rockstar 450 Plates Are Used

Chemicals, Petrochemicals, Oil & Natural Gas Organization, Fats, Fertilizers, Sugar Mills & Distilleries, Cement Industries, Ship Builders, Paper Industries, Pumps, Automation, Paints, Steel Industries, etc.
